Insight SIP's Bluetooth Low Energy (BLE) Modules

Bluetooth Low Energy (BLE) solutions and Bluetooth Smart Modules from Insight SIP are perfectly suited for devices requiring low cost and low power wireless connectivity. Insight SIP's Bluetooth Low Energy (BLE) products including modules, sensors and beacons, as well as corresponding development kits.



ISP1507 Premium Bluetooth Low Energy 5 Ready / ANT+ / NFC Combo Module

The smallest & most powerful Bluetooth Low Energy (BLE) module on the market, offering a full Bluetooth 5 Ready stack and IPv6 connectivity.

   MODULE            DEV KIT          TEST BOARD
ISP130301

ISP130301 Bluetooth Low Energy V4.2 Compliant Module with Antenna & MCU

The perfect balance of power and performance at a competitive price for your Bluetooth Low Energy (BLE) Applications.

   MODULE            DEV KIT           TEST BOARD
ISP1302

ISP1302 Lite BLE V4.2 Compliant Module with Antenna & MCU

The lowest cost Bluetooth Low Energy (BLE) Module, whilst still benefiting from Insight SIPs miniature module technology.

   MODULE              DEV KIT         TEST BOARD
ISP091201

ISP091201 Bluetooth Low Energy V4.0 Module with Integrated Antenna

The ideal choice for customers who want to add radio connectivity to an existing application.

    MODULE            DEV KIT         TEST BOARD

Insight SIP’s Bluetooth Low Energy (BLE) Module Range

Our modules are based on Bluetooth Low Energy (BLE) chips from Nordic Semiconductor. Our latest module is as small as 8.0 x 8.0 x 1.0 mm. All modules integrate the antenna, the RF matching circuit, all decoupling and load capacitors plus crystal oscillators. As our modules have several end applications, the antenna was designed to be compatible with several ground plane sizes such as USB dongle or cell phone, illustrating Insight SiP’s expertise in RF & Front End miniaturization and antenna integration.

The modules are specifically designed for PC, smart phone peripherals, IoT smart objects and M2M applications in following fields: domotic / home automation, fitness, healthcare, industrial, sport, wearable devices, etc. Ultra low power consumption and advanced power management enables battery lifetimes up to several years on a coin cell battery. All our modules are full certified by the Bluetooth SIG and by global regulatory bodies such as the FCC, CE, Telec, etc.
